AudioPressBox is a professional press conference audio distribution amplifier.

Mult box or also known as press box is a device with multipe outputs of a single audio source. It allows people that are connected to it, record the audio signal.

Mult box is a professional solution for every press event that allows all members of the press to gain full access to the audio.

AudioPressBox’s® implements and distributes an input signal to multiple independent outputs. Here at AudioPressBox we take wishes and requests of our customers into serious consideration and that is why we managed over time through a close work with our clients to manufacture unique range of Mult Box devices suitable for both System Integrators and Rental Companies.

We ensure that every device has the highest quality standards and always exceeds our customers expectations.

AudioPressBox® is a mult box device developed and manufactured by a European company MediaTech Central Europe.

To see more AudioPressBox Videos on YouTube click here.



Categories

Portable


Installation


Expanders


Accessories


Portable AudioPressBox mult box devices are suitable for both indoor and outdoor press conferences. The devices include a rechargeable Li-Ion accu pack, and do not require power from the main to operate, gives the user countless possibilities of use.
learn more..

Fixed installation AudioPressBox devices are valued by the system integrators as it gives them a lot of options for the use in their projects. The wide range of mult box devices gives the freedom to choose the right solution for every single project.
learn more..

AudioPressBox expanders are both portable and fixed installation expanders of the main unit that allow everyone to choose the exact type of unit which they need. Whether it is an in wall or stage box design, you will always find only the perfect quality.
learn more..

Various AudioPressBox accessories such as special cables for journalists and protective cases that can make your life at a press conference easier when the journalists forget to bring their own cables along.
learn more..

This is the latest AudioPressBox catalog for 2020.

These are the data sheets for all the AudioPressBox devices.

These are the high-res pictures for all the AudioPressBox devices.

All aplications for AudioPressBox devices.

  • 1 channel DANTE input - RJ45 ethercon

  • 12 high quality balanced, individually transformer isolated outputs.

  • each output is switchable between Line or MIC level.

  • the unit is powered only via PoE from DANTE network

  • thanks to DANTE patching you can easily expand number of channels or number of outputs by adding other APB-112 SB-D

  • 2 MIC (phantom power) / LINE Inputs – balanced with gain control and 26dB PAD

  • Each Input is routable to A/(A+B)/B Outputs Group

  • 24 High quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • 2 internal Output Groups: 12x Output A and 12x Output B

  • Switchable High-Pass filter for each Input channel

  • Switchable Compressor and Limiter for each Input channel

  • PFL/AFL for each Input/Output channel

  • Constant level Test signal oscillator with no mistake switch operation

  • Headphones control Output for PFL/AFL

  • Li-Ion AccuPack with microprocessor controlled battery management

  • 10 hour full load capacity. Note: AccuPack is placed inside the unit


D100 (x1 included)

  • Portable Drive Unit

  • 1 Balanced LINE Input

  • Switchable High-Pass filter

  • Switchable Compressor and Limiter for Input channel

  • 2 separately buffered Outputs for 6 AudioPressBox 8-output expanders.



008 SB-EX (x4 included)

  • 1 Balanced LINE Input

  • 8 High quality internal balanced Outputs, independent transformer isolated

  • Each Output is switchable between MIC or LINE level


  • 1 MIC (phantom power) / LINE Input – balanced with gain control and 26dB PAD

  • 16 High quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • 2 internal Output Groups: 8x Output A and 8x Output B

  • Switchable High-Pass filter for each Input channel

  • Switchable Compressor and Limiter for each Input channel

  • Constant level Test signal oscillator with no mistake switch operation

  • Headphones control Output

  • 1 LINE Input – balanced with ajustable gain -10db to +20 dB

  • 16 High quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • Built in High-Pass filter on the frequency of 40Hz

  • Switchable Compressor and Limiter for Input channel

  • Nominal Output level is selectable -6 dBu, 0 dBu, +4 dBu and +6 dBu

  • Li-Ion AccuPack with microprocessor controlled battery management

  • 10 hour full load capacity. Note: AccuPack is placed inside the unit

  • 1 LINE Input – balanced with ajustable gain -10db to +20 dB

  • 16 High quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • Built in High-Pass filter on the frequency of 40Hz

  • Switchable Compressor and Limiter for Input channel

  • Nominal Output level is selectable -6 dBu, 0 dBu, +4 dBu and +6 dBu

  • Li-Ion AccuPack with microprocessor controlled battery management

  • 10 hour full load capacity. Note: AccuPack is placed inside the unit

  • Rack Drive Unit

  • 1 Balanced LINE Input

  • Switchable High-Pass filter

  • Switchable Compressor and Limiter for Input channel

  • 2 separately buffered Outputs for 6 AudioPressBox 8- LINE/MIC output expanders.

Have you got any questions?
Let us help you!

  • 1 channel DANTE input - RJ45 ethercon

  • 12 high quality balanced, individually transformer isolated outputs.

  • each output is switchable between Line or MIC level.

  • the unit is powered only via PoE from DANTE network

  • thanks to DANTe patching you can easily expand number of channels or number of outputs by adding other APB-112 OW-D

  • 24 High quality independent transformer balanced and isolated outputs

  • Each Output   is switchable between MIC or LINE level

  • 2 internal Output Groups: 12x Output A and 12x Output B

  • 8 High quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • 2 internal Output Groups: 4x Output A and 4x Output B

  • 8 high quality independent transformer balanced and isolated outputs

  • Each Output is switchable between MIC or LINE level

  • 2 internal Output Groups: 4x Output A and 4x Output B
